CA-GNSS-PRO | High-Precision GNSS Monitoring Receiver

Product Overview

The CA-GNSS-PRO is a dedicated multi-star, multi-frequency GNSS monitoring all-in-one receiver for surface displacement monitoring. With BeiDou-3 (BDS-3) support, high precision, low power and easy installation, it deploys complete monitoring stations powered by a small solar system at under 2W.

Outputs: high-precision surface displacement, acceleration & tilt
Edge computing: RTK, on-device / backend static solving, alarm triggering
Sensor integration: MEMS-triggered RTK; powers & connects RS485 sensors
Storage: built-in storage for >2 years of 15s-raw data
Smart: timed sleep, battery monitoring, remote upgrade & diagnostics
Design: all-in-one, IP68, simple installation, low power

Technical Specifications

Satellite systems	GPS (L1C/A, L2C) · BeiDou BDS-3 (B1I, B2I) · GLONASS (L1OF, L2OF) · Galileo (E1B/C, E5b)
Displacement accuracy	Horizontal: ±(2.5mm + 0.5ppm·D) RMS; Vertical: ±(5mm + 0.5ppm·D) RMS
RTK accuracy	Horizontal: ±1.0cm + 1ppm; Vertical: ±2.0cm + 1ppm
Differential format / rate	RTCM 3.2 / 5Hz
Computation	On-device, server-based & RTK real-time; 10-min static solution output
Integrated sensing	MEMS accelerometer & tilt sensor; powers/supplies RS485 sensors
Communications	4G · LoRa · RS485; optional Wi-Fi / Bluetooth / NB-IoT
Power	<2W, 9–15V input; solar-system ready; auto power-on
Storage	32GB built-in (expandable to 512GB)
Enclosure / rating	Magnesium-aluminum alloy, IP68
Operating temperature	-30°C ~ +65°C (storage -40°C ~ +85°C)
Mounting	5/8" anti-theft locking nut

Applications

Deformation & displacement monitoring for critical infrastructure

Slope & landslide Dam & reservoir safety Bridge & SHM Tunnel & excavation Mining pit & tailings dam Foundation & settlement High-speed rail & subgrade Urban lifeline
